Features:
• Light weight
• 100%waterproof
• anti-aging & UV resistance
• printable & soldable
• high tear & tensile strength
• cold craking resistance
• Long worklife guarantee
Features:
• Light weight
• 100%waterproof
• anti-aging & UV resistance
• printable & soldable
• high tear & tensile strength
• cold craking resistance
• Long worklife guarantee
|
Technical |
Technical data |
detection basis |
|
Base Fabric |
100% polyester |
DIN EN 60001 |
|
Total Weight(gsm/㎡) |
750gsm/㎡ |
DIN EN ISO 2286-2 |
|
Total Thickness(mm) |
0.58±0.02mm |
|
|
Tensile Strength(Warp/Weft)(N/5cm) |
3200/2800N/5cm |
DIN 53354 |
|
Tear Strength(Warp/Weft)(N) |
400/300N |
DIN 53363 |
|
Adhesion(N/5cm) |
>110N/5cm |
DIN 53357 |
|
Threshold Temperature |
-30℃/+70℃ |
DIN EN 1876-2 |
|
Surface Treatment |
top side acrylic |
|
|
Flame Retardancy(can be customized) |
B1 |
DIN4102 |
